Crono Thermostats Orkli d'ambiance filaires cable, On/Off

Crono Thermostats Orkli d'ambiance filaires cable, On/Off

Digital chronothermostat ON/OFF model that allows the regulation of the daily heating temperature in half-hour intervals, being able to configure 2 types of temperature (comfort and savings).

To connect this unit to the network through the terminals, go inside the thermostat and proceed with the wiring as indicated in the graphic description.

Note, make sure all cables are connected according to the wiring diagrams and keep them away from water, mud and other materials to prevent damage to the unit.

Features
Wiring diagram
Control solutions
Differential adjustment
Switching: 0.6 ºC (variable from 0.4 ºC to 2 ºC)
Temperature adjustment range: 10 ºC – 30 ºC
Temperature range: 0 ºC – 45 ºC
Storage temperature range: 0 ºC – 50 ºC
Screen accuracy: 0.5 ºC
LCD screen: segment
Humidity range: 5 - 95% relative humidity (no condensate)
IP Grade: IP20
Case: Fireproof PC
Maximum load capacity: 250V / 10A (resistive load)
Power: 3 V (2 alkaline batteries)
