Powder extinguisher Fire Ice FI 2000 ABC 2 kg
Instructions for use
1. Remove the O-ring and the gasket
2. Press the handle. Attack the fire in the direction of the wind, you must turn your back to the wind to avoid the smoke and heat preventing you from getting close enough.
3. Pour the extinguishing agent into the base of the fire, trying to keep the bottle vertical.
Installation
The fire extinguisher must be installed less than 5 meters from the main entrance and near the emergency exits. Fire extinguishers must always be hung at a height between 80 cm and 120 cm from the ground, taking the top of the extinguisher as a reference, according to RD513/17
Model FI 2000
Cylinder length diameter (mm) 101.6 × 620
Capacity (L) 3.1
Fire extinguisher tare (kg) 5.0 to 5.3
Fire extinguisher weight (kg) Tolerance -5% 7.0 to 7.3
CO2 (kg) 2
Maximum working pressure (bar) 180
Test pressure (bar) 250
Tare pressure safety disk (bar) 190
Temperature -20ºc and +60ºc
Fire class BC 34B
Box dimensions (m/m) 120x140x670
Weight with housing and diffuser 7.30
