Panasonic PAW-A2W-V-L heat recovery unit
Heat recovery unit designed for ventilated areas up to approximately 140 m2
Energy-efficient rotary heat exchanger with fans with EC technology
Humidity transfer function to minimize condensation in supply air in winter
Control via touch screen and start-up wizard for easy commissioning
Modbus communication via RS-485
Possibility to control Aquarea H and J series heat pumps from the PAW-A2W-VENTA control panel if both units are connected via the Modbus interface (the PAW-AW-MBS-H and PAW-VEN-ACCPCB interfaces are necessary).
Rated air flow of 204 m3/h
Air inlet on the left
Energy class A
230 V power supply
Sound pressure 38 dB
Single-phase power supply
50Hz power supply
Sound pressure 40 dB(A)
Height 450 mm
Width 598 mm
Depth 500 mm
Net weight 46 kg
