Fire Ice ABC Powder Extinguisher 5 kg
Instructions for use
1. Remove the O-ring and gasket
2. Press the handle. Attack the fire in the direction of the wind, you must turn your back to the wind to avoid the smoke and heat preventing you from getting close enough.
3. Pour the extinguishing agent into the base of the fire, trying to keep the bottle upright.
Installation
The fire extinguisher must be installed less than 5 meters from the main entrance and near the emergency exits. Fire extinguishers must always be hung at a height between 80 cm and 120 cm from the ground, taking the top of the extinguisher as a reference, according to RD513/17
Type: 5 kg
Working pressure (bar): 150
Test pressure (bar): 250
Temperature -30ºc and +60ºc
BC fire class: 89B
Model: C5
Diameter (mm): 136
Capacity (L): 7.5
Cylinder length (mm): 770
Fire extinguisher tare (kg): 8.23
Fire extinguisher weight (kg) Tolerance -5%: 13.23
CO2 (kg): 5
Box dimensions (m/m): 790x210x150
Weight with box and diffuser: 14.40
