Ariston Vitrified Accumulator BCH CD1 120 ARI EU 124 liters

Ariston Vitrified Accumulator BCH CD1 120 ARI EU 124 liters

BCH CD1 120 EE ARI is an indirect heating hot water tank for gas or electric boilers. With a volume of 124 liters and a heat exchanger surface (heating coil) of 0.96 m2, it offers enough space for efficient water heating, its floor-standing design and top connection allow easy installation and connection to different types of boilers or renewable energy sources.

Thanks to the heat exchanger located along the entire length of the tank, uniform and rapid heating of the water is ensured, while the formation of scale is minimized, the high performance and efficiency of the exchanger guarantee efficient heating of the water throughout the tank volume.

For corrosion protection, it is equipped with magnesium and active titanium anodes, which extend the service life of the tank and provide protection against corrosion, the stationary or suspended installation option offers flexibility in the placement of the water tank. The maximum heating output of up to 25 kW provides sufficient power to heat water as needed, with the BCH CD1 120 EE ARI tank you benefit from a reliable and efficient partner to provide hot water to your home.

Suspended/standing installation
Heat loss 1.55 kWh/24h
Power standard 25 kW
Energy class C (in the A+/F range)
Load profile OV L
Max. operating pressure of the exchanger 7 bar
Exchanger pressure drops at 900 l/h 40 mbar
The surface area of ​​the double shell of the heat exchanger is 0.97 m2
Maximum flow rate (T primary circuit = 80°C, 2000 l/h, ΔT 35°C) 90
Depth 60 cm
Volume 124 liters
Width 60 cm
Height 104 cm cm°C
Net weight 40 kg
Gross weight 44 kg
